SKU: MEN-3406
/
Tax included. Shipping calculated at checkout.
  • Rated for use in Singapore
  • Local Service Center
  • Delivery options available
  • In stock
  • Inventory on the way
MEN-3406 is a managed 4-port, 10/100/1000 RJ45 downlink, and 2-port FX/GbE SFP ports uplink, designed for broadband indoor office applications with basic needs in network infrastructure. To keep regular internet speeds this device uses the Quality of Service (QoS) protocol to balance the use of bandwidth. It meets the requirements of triple-play broadband services along with low latency streaming - TV, internet, and phone.

The management features allow safe, easy access and configuration of this device, using the web GUI and command line. It is designed to continue working during sudden power cuts with the help of an emergency battery parallel to the DC power jack input. To reduce the need for continuous maintenance, the fanless design of this switch avoids the accumulation of debris in the device, which also allows it to operate silently and hinder noise disturbances. Feeds power through Terminal Block and has a temperature operation of 0°C~60°C (32°F~140°F) allows for indoor network room in-rack or cabinet storage.

Customer Reviews

Be the first to write a review
0%
(0)
0%
(0)
0%
(0)
0%
(0)
0%
(0)
More from All Products
CADYCE CA-U34H USB 3.0 4-Port Hub
CADYCE CA-U34H USB 3.0 4-Port Hub
CADYCE CA-U34H USB 3.0 4-Port Hub
Enquire with us
Sold Out
HP Portable SSD P500 250GB/500GB/1TB
HP Portable SSD P500 250GB/500GB/1TB
HP P500 Portable SSD
Enquire with us
GOOBAY CAT 7 S/FTP PIMF RJ45 LSZH - Yellow
GOOBAY CAT 7 S/FTP PIMF RJ45 LSZH - Yellow
GOOBAY LAN CAT 7 S/FTP PIMF RJ45 LSZH Patch Cable - Yellow
Enquire with us
GOOBAY CAT 7 S/FTP PIMF RJ45 LSZH - Blue
GOOBAY CAT 7 S/FTP PIMF RJ45 LSZH - Blue
GOOBAY LAN CAT 7 S/FTP PIMF RJ45 LSZH Patch Cable - Blue
Enquire with us
Sold Out
Arlo Ultra 2 VMS5340 4K Ultra HD Wireless HDR Security Camera System
Arlo Ultra 2 VMS5340 4K Ultra HD Wireless HDR Security Camera System
ARLO Ultra 2 VMS5340 4K Ultra HD Wireless HDR Security Camera System
Enquire with us
GOOBAY LAN CAT 6 SOLID U/UTP WEISS CCA CPR
GOOBAY LAN CAT 6 SOLID U/UTP WEISS CCA CPR
GOOBAY LAN CAT 6 SOLID U/UTP WEISS CCA CPR
Enquire with us
Datasheet
Product Highlights
  • 4 x 10/100/1000 RJ45 ports for broadband office applications with basic needs in infrastructure
  • 2 x FX/GbE SFP uplink ports for long-distance connectivity and cascading
  • Storm control and QoS prioritizes traffic to support efficient work
  • IP30 metal housing
  • Operating temperatures 0°C~60°C (32°F~140°F)
Features

Unparalleled Network Performance

Storm control and traffic monitoring to limit unwanted incoming traffics based on defined parameters for prevention of LAN disruption.

Robust Electrical and Electromagnetic Safeguard

Engineered to withstand EMI (electromagnetic interference), ESD (Electrostatic discharge), power surge, over voltage, over current, and reverse polarity.

Redundant Power System

DC powered with optional battery backup.

Efficient Traffic Prioritization

Effective QoS mechanisms for priority assignment and transmission of dedicated traffics to specific applications.

Efficient Network Monitoring and Management

SNMP (Simple Network Management Protocol) v1/v2c/v3 and RMON (Remote Monitoring) for real-time traffic analysis, remote monitoring, and management.

Specifications

Standards

IEEE 802.310BASE-T
IEEE 802.3u 100BASE-TX
IEEE 802.3ab1000BASE-T
IEEE 802.3u 100BASE-FX
IEEE 802.3z 1000BASE-SX/LX
IEEE 802.3Nway Auto-negotiation
IEEE 802.3x Flow Control
IEEE 802.3ad Link Aggregation
IEEE 802.3azEnergy Efficient Ethernet (EEE)
IEEE 802.1ABLLDP
IEEE 802.1DSTP
IEEE 802.1wRSTP
IEEE 802.1pClass of Service
IEEE 802.1QVLAN Tagging
IEEE 802.1XPort Authentication

Interface

Ports4 x 10/100/1000BASE-T (RJ45)
2 x 100FX/GbE SFP Slots
LED PanelPWR, POST, 1000, LNK/ACT, SFP

Power

Input VoltageMEN-3406: 12V DC/1A Power Adapter
MEN-3406B: 15V DC/2A (Battery charge)
Redundant inputs: 12V Battery (only for battery charge version)
Connection DC Jack
Power Consumption6W (System)

Mechanical and Environment

HousingMetal Case
MountingDIN-Rail
Operating Temperature 0°C~60°C (32°F~140°F)
Storage Temperature -20°C~70°C (-4°F~158°F)
Operating Humidity 10 to 95% RH (non-condensing)
Storage Humidity5 to 95% RH (non-condensing)
Weight529 g (1.17 lb)
Dimension (WxHxD)50 x 115.8 x 99.6 mm (1.97 x 4.56 x 3.92 in)

Ordering Information

ModelDescription
MEN-3406 Managed 4 x 10/100/1000 RJ45 & 2 x FX/GbE SFP Switch, w/ External AC Power Adapter
MEN-3406B Managed 4 x 10/100/1000 RJ45 & 2 x FX/GbE SFP Switch, w/ External AC Power Adapter, Battery Charge Function Included (60°C)
