A new way to deploy Audio Visual technology in meeting spaces
A full range of components and Room Systems
Chassis Display Mounts
Single & Dual Display Solutions
Huddle Systems
Collaboration Furniture
Furniture
Technology Enabled Tables
Product Packages
Curated Room Packages
Chassis Display Mounts
Modular Display Mount Solutions
Introduction
Modular mounting solution for single/dual displays from 55” to 105” that also provides integral enclosed space for equipment and cabling. Removes the requirement for expensive building work and equipment traditionally housed in a rack or credenza.
Features of an Ashton Bentley Chassis
Quick to install. Assembled in minutes. Simple to relocate.
- Minimal building work. Just tether the chassis to the wall. The weight of the display is on the floor, not the wall.
- Freestanding bases can be used in front of a glass wall or open space.
- Mobile bases allow for easy relocation of the chassis on site.
- Displays mounted at the correct height and level, every time.
- No special cabling requirements. Cables can be run from the floor or wall.
- Equipment storage within the chassis removing the requirement for an equipment rack in a cupboard or credenza.
- Effortlessly accommodate single or dual displays
- Display agnostic. Mount almost any size of display from all manufacturers.
- Fixings available for almost any Videobar, Camera and Codec/NUC
Base Options
Wall Fixing
Supplied as standard. These brackets anchor the Chassis to the wall. The weight of the chassis and display remains down on the floor, not the wall.
Mobile
For manoeuvrability on site. Simply secure the optional Mobile Base to the standard Floor-to-Wall Chassis with the supplied Knobs.
Freestanding
Recommended for installation
(In front of a glass wall or in free space / In a non-permanent location / In a listed building where no building work is permitted).
Simply secure the optional Freestanding Base to the standard Floor-to-Wall chassis with the supplied knobs.
Camera Positions
Correct camera placement is critical to deliver a natural and engaging collaborative experience.
Designed to remove the time-consuming decision making process to get the camera in the right location.
Options for camera above and below for all display sizes and applications.
A range of mounting brackets for all leading camera and Videobars makes the fixing of these simple and secure.
Display Compatibility
Mount almost any display between 43” and 105” from all the main manufactures.
Also mount all-in-one panels from Neat & DTEN. Got any special requirements to mount ‘unusual’ displays or other panels, then contact us. We will do our best to find a solution for you.
The only way to mount a display
Mounting bar/rail system makes installation incredibly simple. Repeatable display mounting with little effort. Displays always at the correct height, level and square. 55”, 65” & 75”
Acoustic Front Covers
A range of colours are available. The front cover below the display, that covers the equipment enclosure, is made from acoustic material. Magnetic fittings allow for toolless access.
Equipment Mounting Options
AB Equipment Bracket
For the DX2 Room Hub and/or BX USB-C Breakout Hub
VESA Chassis Bracket Kit for 3rd Party Products
VESA fixings and cable tie points that provides mounting for a variety of products. The bracket can be placed in several locations in the Chassis
Rack Mount Chassis Brackets
1RU & 2RU brackets that securely locates rack mountable products.
Huddle Room Systems
Solutions for small spaces
Specifically designed to maximise the collaboration experience.
Have your own table? No problem. The TX Table Hub and Tablebox for laptop connectivity, can easily be installed.
- Shaped and rectangular designs for small, medium and large spaces
- Concealed technology and cable management
- Conveniently located Power & USB Charging sockets
Ergonomics
Ashton Bentley tables have been designed with comfort, functionality, and the movement of the human body in mind, with focus being made on the following:
- Reach - All peripherals and devices are within easy reach.
- Sight - Users have clear line of sight to interact and connect with other users and presentation devices.
- Placement of product - All items are located in a convenient place, are accessible, and do not impede the user’s work space.
- Body position - The user is placed in a comfortable position without causing fatigue or strain.
Spacing
Generous space is allocated to each user and personal devices allowing for a comfortable and unclutt ered experience. Strategic placement of the tables legs offers strength and rigidity, as well as ample space for users legs.
Enclosed Electronics
Under-table cover hides exposed electronics / cables
Internal Cable Tray
Allowing cables and connectivity to pass between legs discretely, without any build works required.
Power Block
Each table leg is supplied with two power sockets and two USB charging sockets. Power can be country specific: UK/USA/EU/INDI
Surface Finishes
Each table is supplied with a high quality and durable surface.
The solid white option is often used in neutral architectural designs. This white has a clear, almost “icy” matt effect that doesn’t reflect light.
The various wood textures are designed to capture the growing popularity of natural wood furniture, with an elegant and natural wood grain structure, enhanced by a depth to the pattern, resulting in a tactile crafted texture
Huddle Range (HST).
Furniture
Designed for today's collaboration technology.
Specifically designed to maximise the collaboration experience
Have your own table? No problem. The TX Table Hub and Tablebox for laptop connectivity, can easily be installed.
- Shaped and rectangular designs for small, medium and large spaces
- Concealed technology and cable management
- Conveniently located Power & USB Charging sockets
Internal Cable Tray
Allowing cables and connectivity to pass between legs discretely, without any build works required.
Enclosed Electronics
Under-table cover hides exposed electronics / cables
Power Block
Each table leg is supplied with two power sockets and two USB charging sockets. Power can be region specific: UK/USA/EU/INDIA
Tablebox
The Tablebox is a discrete and intuitive table top enclosure providing AV connectivity and cable management for up to two users.
- The Tablebox offers quick assembly and configuration allowing the enclosure to fix to the furniture without the need for tools or additional parts
- Compatible with up to 1x HDMI (2.8m) and 1x USB-C (2.5m) cables and/or Retractor cable retraction modules
- Tablebox is available as standard on all existing Ashton Bentley furniture offerings.
Tablebox Touch Panel Module
Designed with an intuitive GUI that presents clear feedback to the user when switching between devices at the table or auxiliary devices withing the system.
Tablebox Retractors
The cable retractor system is a concealed self-winding cassette which allows easy access to a combination of HDMI (2.8m) or USB-C (2.5m) connectors. Mounted within the leg structure of the AB furniture range the retractors reduce table cable clutter and ensure that connectivity is available whenever required.
Surface Finishes
Each table is supplied with a high quality and durable surface.
The solid white option is often used in neutral architectural designs. This white has a clear, almost “icy” matt effect that doesn’t reflect light.
The various wood textures are designed to capture the growing popularity of natural wood furniture, with an elegant and natural wood grain structure, enhanced by a depth to the pattern, resulting in a tactile crafted texture.
Surface Finishes
Each table is supplied with a high quality and durable surface.
The solid white option is often used in neutral architectural designs. This white has a clear, almost “icy” matt effect that doesn’t reflect light.
The various wood textures are designed to capture the growing popularity of natural wood furniture, with an elegant and natural wood grain structure, enhanced by a depth to the pattern, resulting in a tactile crafted texture.
Chamfered Edge - Shaped Tables Only
Straight Edge - Rectangular & TP Tables
Shaped Table Range (ST).
Optimised for Video
Rectangular Table Range (RT).
Optimised for Space
Immersive Table Range (TP).
Optimised for Engagement
Shaped Table Range (ST).
Rectangular Table Range (RT).
Immersive Table Range (TP).
Product Packages
Curated Room Packages Optimised for performance
Click Image to View CAD Plan
Huddle43.ST2
Package consists of:
- 1x 43" 4K Display
- 1x 43 Floor-to-Wall Chassis
- 1x BX USB-C Breakout Hub
- 1x Tablebox + Touchpanel
- 1x USB-C Retractor
- 1x Huddle ST2 Shaped 2 Seat Table Assembly
Huddle43.ST3
Package consists of:
- 1x 43" 4K Display
- 1x 43 Floor-to-Wall Chassis
- 1x BX USB-C Breakout Hub
- 1x Tablebox + Touchpanel
- 1x USB-C Retractor
- 1x Huddle ST3 Shaped 3 Seat Table Assembly
Click Image to View CAD Plan
Click Image to View CAD Plan
Huddle55.ST5
Package consists of:
- 1x 55" 4K Display
- 1x 55/65 Floor-to-Wall Chassis
- 1x BX USB-C Breakout Hub
- 1x Tablebox + Touchpanel
- 1x USB-C Retractor
- 1x Huddle ST5 Shaped 5 Seat Table Assembly
One55.RT5
Package consists of:
- 1x 55 4K Display
- 1x 55-65 Floor-to-Wall Chassis
- 55-65-75 Single-Dual Free Standing Base (OPTION)
- 1x DX2 Room Hub / TX2 Table Hub
- 1x Tablebox + Touchpanel
- 1x USB-C Retractor
- 1x HDMI Retractor
- 1x RT5 Rectangular 5 Seat Table Assembly
Click Image to View CAD Plan
Click Image to View CAD Plan
One75.RT9
Package consists of:
- 1x 75 4K Display
- 1x 55-65 Floor-to-Wall Chassis
- 55-65-75 Single-Dual Free Standing Base (OPTION)
- 1x DX2 Room Hub / TX2 Table Hub
- 1x Tablebox + Touchpanel
- 1x USB-C Retractor
- 1x HDMI Retractor
- 1x RT9 Rectangular 9 Seat Table Assembly
Two65.ST7
Package consists of:
- 2x 65" 4K Display
- 2x 55-65 Floor-to-Wall Chassis
- 55-65-75 Single-Dual Free Standing Base (OPTION)
- 1x DX2 Room Hub / TX2 Table Hub
- 1x Tablebox + Touchpanel
- 1x USB-C Retractor
- 1x HDMI Retractor
- 1x ST7 Shaped 7 Seat Table Assembly
Click Image to View CAD Plan
Click Image to View CAD Plan
One105.TP4
Package consists of:
- 1x 105 4K Display
- 1x 55-65 Floor-to-Wall Chassis
- 55-65-75 Single-Dual Free Standing Base (OPTION)
- 1x DX2 Room Hub / TX2 Table Hub
- 1x Tablebox + Touchpanel
- 1x USB-C Retractor
- 1x HDMI Retractor
- 1x TP4 Immersive 4 Seat Table Assembly
Product Packages
Curated Room Packages Optimised for performance
Click Image to View CAD Plan
Huddle43.ST2
Package consists of:
- 1x 43" 4K Display
- 1x 43 Floor-to-Wall Chassis
- 1x BX USB-C Breakout Hub
- 1x Tablebox + Touchpanel
- 1x USB-C Retractor
- 1x Huddle ST2 Shaped 2 Seat Table Assembly
Click Image to View CAD Plan
Huddle43.ST3
Package consists of:
- 1x 43" 4K Display
- 1x 43 Floor-to-Wall Chassis
- 1x BX USB-C Breakout Hub
- 1x Tablebox + Touchpanel
- 1x USB-C Retractor
- 1x Huddle ST3 Shaped 3 Seat Table Assembly
Click Image to View CAD Plan
Huddle55.ST5
Package consists of:
- 1x 55" 4K Display
- 1x 55/65 Floor-to-Wall Chassis
- 1x BX USB-C Breakout Hub
- 1x Tablebox + Touchpanel
- 1x USB-C Retractor
- 1x Huddle ST5 Shaped 5 Seat Table Assembly
Click Image to View CAD Plan
One55.RT5
Package consists of:
- 1x 55 4K Display
- 1x 55-65 Floor-to-Wall Chassis
- 55-65-75 Single-Dual Free Standing Base (OPTION)
- 1x DX2 Room Hub / TX2 Table Hub
- 1x Tablebox + Touchpanel
- 1x USB-C Retractor
- 1x HDMI Retractor
- 1x RT5 Rectangular 5 Seat Table Assembly
Click Image to View CAD Plan
One75.RT9
Package consists of:
- 1x 75 4K Display
- 1x 55-65 Floor-to-Wall Chassis
- 55-65-75 Single-Dual Free Standing Base (OPTION)
- 1x DX2 Room Hub / TX2 Table Hub
- 1x Tablebox + Touchpanel
- 1x USB-C Retractor
- 1x HDMI Retractor
- 1x RT9 Rectangular 9 Seat Table Assembly
Click Image to View CAD Plan
Two65.ST7
Package consists of:
- 2x 65" 4K Display
- 2x 55-65 Floor-to-Wall Chassis
- 55-65-75 Single-Dual Free Standing Base (OPTION)
- 1x DX2 Room Hub / TX2 Table Hub
- 1x Tablebox + Touchpanel
- 1x USB-C Retractor
- 1x HDMI Retractor
- 1x ST7 Shaped 7 Seat Table Assembly
Click Image to View CAD Plan
One105.TP4
Package consists of:
- 1x 105 4K Display
- 1x 55-65 Floor-to-Wall Chassis
- 55-65-75 Single-Dual Free Standing Base (OPTION)
- 1x DX2 Room Hub / TX2 Table Hub
- 1x Tablebox + Touchpanel
- 1x USB-C Retractor
- 1x HDMI Retractor
- 1x TP4 Immersive 4 Seat Table Assembly
About Ashton Bentley
Ashton Bentley by Kramer provides efficient and scalable AV solutions for collaboration spaces, enabling seamless integration with major video conferencing platforms. The systems are designed for quick assembly and low maintenance, ensuring reliable performance and reduced downtime.
Streamline your meeting environments with Ashton Bentley's modular designs that prioritise functionality and ease of use.
Simple to buy, use, install and maintain.
