VIEWSONIC ViewBoard IFP92UW 92” 5K 21:9 ultrawide interactive display with extra horizontal screen space
SKU: IFP92UW
OVERVIEW
The ViewBoard® IFP92UW delivers an expansive interactive experience with its 21:9 aspect ratio, optimized for Microsoft Teams Rooms and Front Row mode, and stunning 5K resolution. This ultrawide 92” display facilitates multitasking with split-screen functionality, enhancing collaboration and productivity in team huddles, meetings, and brainstorming sessions. It boasts highly responsive 50-point touch capabilities that capture every input naturally and intuitively, offering pen-on-paper precision, complemented by seamless wireless screen casting through vCast. Additionally, an 8-microphone array and 60W soundbar ensure optimal audio clarity for both in-room and remote participants.
Make Space for Collaboration
21:9 Interactive Display for Productive Meetings
Seamless Integration to Any Collaborative Spaces
BYOD Meetings
Corporate Training
Interactive Exhibitions
Immersive Visuals
Seamless Collaboration
Enhanced Productivity
Centralized Device Control
Immersive Visuals
More Space for Enhanced Collaboration
Offering 33% more screen space than a conventional 16:9 display of the same size, the 21:9 aspect ratio of the ViewBoard IFP92UW enhances multitasking and collaboration by enabling users to view more tools, documents, and information simultaneously during meetings.
Superior Detail, Flawless Visibility
Featuring 5K resolution, the ViewBoard IFP92UW delivers unparalleled image sharpness and detail, complemented by a 178-degree viewing angle that guarantees flawless visibility across the entire room.
Seamless Collaboration
Hybrid Meetings
Enhance inclusivity in hybrid meetings with an ultrawide display optimized for Microsoft Teams Rooms Front Row mode, simultaneously showcasing remote attendees, content, and chat—all on one screen.
Crystal-clear Hybrid Communication
Equipped with powerful speakers and an 8-microphone array that detects and reduces background noise, the ViewBoard IFP92UW ensures seamless communication during all video conferences and presentations.
Seamless Team Collaboration
Supporting up to 50 touch points, the ViewBoard IFP92UW enhances team collaboration by enabling multiple users to interact with the screen simultaneously using their fingers or a stylus, boosting brainstorming sessions and group activities.
Multi-device Wireless Screen Sharing
Enjoy instant, simultaneous wireless screen sharing of up to 9 devices through vCast for effective communication and efficient collaboration during team meetings.
Fast and Reliable Wireless Connectivity
Upgrade the ViewBoard IFP92UW with an optional Wi-Fi module for seamless internet access. Additionally, the device can double as a hotspot to ensure a stable, wireless internet connection for the meeting room.
Enhanced Productivity
Efficient Multitasking
Enhance meetings and collaborative sessions with multi-window and split-screen modes. Utilize multi-window mode to display up to four windows simultaneously for a comprehensive document overview during brainstorming sessions. Sketch on the board or share resources while simultaneously monitoring the ongoing video conference in split-screen mode.
*Multi-window mode allows for simultaneous display of embedded apps and one source input.
Boost Productivity with Streamlined Connectivity
With dual USB-C ports, simply plug in your laptop to instantly benefit from power charging, fast data transfer, multimedia broadcasting, and Ethernet connectivity—all through a single cable.
Maximize Productivity with Integrated Windows Experience
Unlock new productivity possibilities and work in the familiar Windows OS by coupling the ViewBoard with an optional slot-in PC. Equipped with dual-band Wi-Fi, Bluetooth, a powerful Intel® Core™ CPU, abundant memory, and ample data storage, this module delivers solid computing performance to support even the most demanding applications.
Tailored to Your Needs
Customize your ultrawide display with ViewSonic’s range of accessories, including Microsoft Teams Rooms solutions, web cameras, motorized carts, and presentation pens, to create the ideal setup for your needs.
Centralized Device Control
Powerful Remote Management
The built-in ViewSonic® Manager software empowers IT teams and administrators to centrally manage one or multiple devices. It enables automatic on/off scheduling to reduce power consumption, multimedia message broadcasting, quick troubleshooting, and facilitates issue resolution. Additionally, it allows for remote optimization of device configurations based on real-time usage reports.*
**An optional ViewSonic® Manager Advanced subscription is required for certain functionalities.
Energy-efficient Solution
The ViewBoard IFP92UW holds the prestigious EPEAT Silver and Energy Star certification, recognizing its adherence to rigorous energy consumption, supply chain carbon emissions, and end-of-life management standards.
Dimensions & I/O Ports
- 1. Power
- 2. USB Type-C 2
- 3. USB3.2 Gen 1
- 4. VESA® Wall Mount (800x600 mm)
- 5. USB3.2 Gen 1
- 6. USB3.2 Gen 1
- 7. Slot-in PC
- 8. AC Power
- 9. WiFi Slot
- 10. SPDIF
- 11. LAN
- 12. RS232
- 13. Touch 3
- 14. USB 2.0
- 15. Touch 1
- 16. Audio In
- 17. HDMI 1
- 18. DP IN
- 19. Audio Out
- 20. USB 3.2 Gen 1 *2
- 21. HDMI Out
- 22. Touch 2
- 23. HDMI 2
- 24. HDMI 3
- 25. HDMI 4
- 26. USB Type-C 1
Panel Size
92"
Panel Type
TFT LCD Module with DLED Backlight, VA
Display Area (mm)
2141.952(H) × 903.636(V) (91.52” diagonal)
Aspect Ratio
21:9
Resolution
WUHD 5120x2160(Pixels)
Colors
1.07G colors (8bits+ 2bits FRC)
Brightness
500nits (Typ.)
Contrast Ratio
OC spec 5000:1 (typ.)
Response Time
<6.5ms
Viewing Angles
H = 178, V = 178 (Typ.)
Backlight Life
50,000hrs (typ.)
Surface Treatment
Panel Hard Coating 3H Glass Anti-Glare + Anti-Fingerprint (7H Mohs; 9H pencil hardness)
Bezel
19.48/19.48/29.78/41.18 mm
Orientation
Landscape
Platform
Processor
RK3588 Octa-Core CPU (A76*4 + A55*4)
RAM
DDR4 8GB
Storage
128GB eMMC
Touch
Type/ Tech
R Recognition
Touch Resolution
32767 x 32767
Touch Point
50
Android and all other channels: 32
Input
HDMI
Rear x4 (HDMI 2.1x 1, HDMI 2.0 x3)
DisplayPort
1
Audio
1
RS232
1
OPS
1 (OPS Slot 80pin)
WiFi
1 (Module Slot)
Output
HDMI
1
Audio
1
SPDIF
1
LAN
RJ45
1 in 1 out (Android & PC 10M/100M/1000Mbps)
USB
Type A
REAR x 1 (USB 2.0 support OTG) REAR x 2 (USB 3.2 Gen 1) FRONT x 2 (USB 3.2 Gen 1) TOP x 2 (USB 3.2 Gen 1)
Type B
REAR x 3 (USB 2.0)
Type C
FRONT x1 (1*PD15W + DP1.2 + Data + 10M/100M sharing, USB 3.2 Gen 1) REAR x1 [1*PD65W(65W with OPS, 100W without OPS) + DP1.2 + Data + 10M/100M sharing, USB 2.0]
Speakers
20W x 2+ 20W x 1 (Subwoofer)
Microphone
Built-in 8 Array Microphone
Type C
FRONT x1 (1*PD15W + DP1.2 + Data + 10M/100M sharing, USB 3.2 Gen 1) REAR x1 [1*PD65W(65W with OPS, 100W without OPS) + DP1.2 + Data + 10M/100M sharing, USB 2.0]
COMPATIBILITY
HDMI
HDMI 1: 5120x2160 @60Hz (YUV444), 5120x2160 @30Hz (YUV420) HDMI 2/3/4: 3840x2160 @60Hz
DisplayPort
5120x2160
Embedded OS
Android 13
Bundled Software
Basic Annotation Software
myViewBoard Whiteboard for Android
Pro Annotation Software
myViewBoard Whiteboard for Windows (embedded in VPC)
Wireless Presentation
myViewBoard Display, vCast, AirSync* *myViewBoard Display will be replaced by AirSync in Q1 2025.
Device Management
ViewSonic® Manager
ViewSonic Launcher
Yes
Special Features
All-in-one USB port
USB 3.2 Gen 1 “SmartPort USB” to all channels
Simple LAN sharing between IFP and slot-in device
(10/100/1000M) (USB Type-C 10/100, Android & PC 10/100/1000)
Light Sensor
Yes
Power
Voltage
100-240VAC +/- 10% Wide Range
Consumption
On: 151.24W(Energy Star) / Off: <0.5W
Ergonomics & Operation Condition
Wall Mount (VESA® )
1000 x 400
Temperature (º C)
0°C to 40°C
Humidity
20% ~ 80% RH non-condensing
Dimensions & Weight
Physical (inch / mm)
86.73 x 39.37 x 3.62 in / 2203 x 1000 x 92mm
Packaging (inch / mm)
92.52 x 44.72 x 8.5 in / 2350 x 1136 x 216mm
Net (lb / kg)
147.7lb/ 67kg
Gross (lb / kg)
183lb/ 83kg
Others
REGULATIONS
cTUVus,FCC/ICES003,CE/EMC,CB/LVD,EAC,UkrSEPRO,UKCA,UK-EEL,LBL,FF,ErP-EEL,Green BOM,RoHS DoC,ErP-Eco,REACH DoC,SCIP,WEEE, EPEAT
PACKAGE CONTENTS
1. 3m power cord by ship area
2. Type C cable 1.8m(USB-IF certified)
3. Remote control with AAA battery x 2
4. 3m touch USB cable(USB 2.0)
5. Touch pen x 2 (VB-PEN-002)
6. Quick Start Guide with Compliance statement
7. RS232 adapter
8. Clamp x 5
9. Camera Plate x 2 (1 for VB-CAM-201, 1 for UMB202)
10. Screw x 8 (camera 2+2, wall mount 4)
11. HDMI cable 3m (HDMI LA certified)
Compatible Slot-in PC
VPC3X series / VPCF5-2A
