High Brightness

Packed with 6,000 ANSI Lumens, it is guaranteed to produce high levels of brightness suitable for large spaces with a lot of ambient light.

6,000 ANSI Lumens

2nd Generation Laser Phosphor Technology

Thanks to 2nd generation Laser Phosphor technology, it improves brightness (by 20%), heat-resistance and reduces the product size in addition to excellent color performance, lamp-free design and instant on/off switch.

Brighter, Smaller, Safer

Reliable Long-Term Performance

Laser technology offers a lifespan of up to 20,000 hours (4 hours per day for more than 13 years) with no degradation in brightness over time so that your installations are consistently vibrant.

20,000 hours Lifespan

No Shadows, No Blinding Lights

With the latest projection technologies from ViewSonic, you'll enjoy all the benefits a short throw projector can offer. When projecting on to a video wall, there are no distracting shadows on the screen image, offering excellent edge blending projection. Plus, a 1.1x optical zoom provides a higher level of flexibility to fit some of the most challenging installation environments.

0.81-0.89 Short Throw

1.1x Optical Zoom

Larger Screen Size, Lower Cost-Per-Inch

Flexible installation and effortless transportation of the projector allows for an up-to-200” image size, which is much larger and easier to install than multiple commercial displays combined.

0.81-0.89 Short Throw     1.1x Optical Zoom

Installation Flexibility

The tool-free, lens shift control knobs make adjusting the projection lens up, down, left, and right easy. It provides flexible installation options with a wide adjustable range (H: +/- 23%, V: +/-50%) and less placement restrictions.

Wide H/V Lens Shift

360° Creative Applications

The projector can freely rotate at any angle vertically to aid with creative applications, allowing projection onto ceilings, walls, or angled signage.

90° Portrait Mode

Portrait mode allows users to turn the projector 90 degrees to increase the vertical field of view and add more applications for projection mapping, staging, and advertising.

Portrait Mode

Dual HDMI 2.0b Supporting 4K/HDR/HLG

It comes with dual HDMI 2.0b / HDCP 2.2 ports, ensuring your access to original 4K quality content with HDR/HLG supported at a 60Hz frame rate from external devices (e.g. Roku stick, 4K Blu-ray player), producing the brightest whites, deepest blacks, and showing more picture detail.

4K/HDR/HLG Support

Lighter Weight & Compact Size

It is almost half the weight and 35% smaller in size when compared with its predecessor, which reduces the cost of transportation and enhances the ease of installation.

Cost-effectively Receive AV Signal over Long Distance

With a built-in HDBT receiver, this projector can receive uncompressed high-resolution video and audio over long distances (100 m for 1080p) via a Cat.5e/6 single network cable and is compatible with any certified HDBaseT transmitter.

HDBaseT Receiver

Non-stop 24/7 Operation

With an advanced cooling design, it enables 24/7 operation without degradation of quality or performance, making the projector ideal for applications that require continuous projection.

LAN Control

Centralized Control for Management Efficiency

This projector comes equipped with Crestron, AMX, PJ Link, ATEN, Extron, and ViewSonic vController, an easy-to-use network management tool.

Comprehensive LAN Control

A Simpler Way to Update Projector Software

ViewSonic Projector Software Update is available online and enables you to keep your projector firmware up to date easily and conveniently with your laptop and USB cable connection; no need to take your projector into a service center for software updates.

Learn more: https://youtu.be/irlhJLpDHas
*The latest projector software update can be found in the download section at the bottom of the page when available.

Easy Image Adjustment

Horizontal and Vertical Keystone correction along with 4 corner adjustment features eliminate crooked or distorted images for a perfectly proportioned picture every time.

H/V Keystone   4 Corner Adjustment

SuperColor™ Technology

ViewSonic’s proprietary SuperColor™ Technology displays a wide color range, ensuring that users enjoy a true-to-life color performance in both bright and dark environments without sacrificing image quality.

Sealed Optical Engine with IP5X

The advanced sealed optical engine prevents dust from entering the projector and affecting the thermal system to ensure that the image quality and long lifespan are maintained.

IP5X

Exterior & Rear I/O Connectors

• 1. Power Key & IR
• 2. Front IR
• 3. Lens
• 4. Lens Shift Control Knob
• 5. Zoom/Focus Ring
• 6. Adjustment Foot
• 7. LED Indicator

• 8. Keypad
• 9. Composite
• 10. S-Video
• 11. USB Type A (5V/1.5A)
• 12. HDMI x 2
• 13. HDBaseT
• 14. Computer In

• 15. Monitor Out
• 16. LAN
• 17. Audio  & Out
• 18. 3D VESA
• 19. 12V Out
• 20. RS-232

Projection System

0.48" WUXGA

Native Resolution

1920x1200

Brightness

6000 (ANSI Lumens)

Brightness (Center Lumens)

6100

Contrast Ratio

3000000:1

Display Color

1.07 Billion Colors

Light Source Type

Laser Phosphor

Light Source Life (hours) with Normal Mode

20000

Light Source Life (hours) with SuperEco Mode

30000 (Eco)

Lens

F=1.83-1.86, f=8.6-9.4mm

Projection Offset

0%

Throw Ratio

0.81-0.89

Optical Zoom

1.1X

Digital Zoom

0.8x-2.0x

Image Size

60"-200"

Throw Distance

1.04-3.83m(100"@1.74m)

Keystone

H:+/-40° , V:+/-40°

Lens Shift V. Range

+50%, -50%

Lens Shift H. Range

+23%, -23%

Audible Noise (Normal)

36dB

Audible Noise (Eco)

29dB

Input Lag

16ms

Resolution Support

VGA(640 x 480) to 4K(3840 x 2160)

HDTV Compatibility

480i, 480p, 576i, 576p, 720p, 1080i, 1080p, 2160p

Video Compatibility

NTSC, PAL, SECAM

Horizontal Frequency

15K-135KHz

Vertical Scan Rate

23-120Hz

Computer in (share with component)

1

Composite

1

S-Video

1

HDMI

2(HDMI 2.0, HDCP 1.4/2.2)

Audio-in (3.5mm)

1

Audio-in (RCA R/L)

1

3D VESA (Sync)

1

HDBaseT

1

Monitor out

1

Audio-out (3.5mm)

1

Speaker

10W x2

USB Type A (Power)

1 (5V/1.5A)

12V Trigger (3.5mm)

1

RS232 (DB 9-pin male)

1

RJ45 (LAN control)

1

USB Type A (Services)

1 (share with USB A Output)

Power Supply Voltage

100-240V+/- 10%, 50/60Hz(AC in)

Power Consumption

Normal: 450W
Standby: <0.5W

Operating Temperature

0~40℃

Carton

Brown

Net Weight

6.5kg (14.33 lbs)

Gross Weight

9kg (19.84 lbs)

Dimensions (WxDxH) with Adjustment Foot

405x305x145mm (15.9x12x5.7 in)

Packing Dimensions

515x490x276mm (20.3x19.3x10.9 in)

OSD Language

English, French, Spanish, Thai, Korean, German, Italian, Russian, Swedish, Dutch, Polish, Czech, T-Chinese, S-Chinese, Japanese, Turkish, Portuguese, Finnish, Indonesian, Hindi, Arabic, Vietnamese, Greek, total 23 languages

User Guide Language

English, S-Chinese, T-Chinese, Indonesian, Finish, French, German, Italian, Japanese, Korean, Polish, Portuguese, Russian, Spanish, Swedish, Turkish, Arabic, Czech, Thai, Vietnamese, total 20 languages

Power Cord

1

VGA Cable

1

Remote Control

1(w/ laser pointer)

QSG

Yes

Warranty Card

Yes (CN Only)
