Features
High Availability (HA)
Non-stop forwarding (NSF) virtual chassis architectures with hitless failover across the stack
Multi-Resiliency
Stacking and distributed link aggregation allow for zero downtime and load balancing capabilities
PVST+ Interoperability
Per VLAN Spanning Tree and Per VLAN Rapid Spanning Tree (PVSTP/PVRSTP)
Link Dependency
Enables or disables ports based on link state of different ports
Advanced IPv4/IPv6 security
Malicious code detection, DHCP Snooping, IP Source Guard protection and DoS attacks mitigation
![](https://cdn.shopify.com/s/files/1/0571/8946/6289/t/7/assets/02-1655782953199.jpg?v=1655782959)
No more Downtime
Or bottlenecks - Spine and Leaf topologies in the same stack with unrivaled ease of use
![](https://cdn.shopify.com/s/files/1/0571/8946/6289/t/7/assets/03-1655782953214.jpg?v=1655782964)
Industry-Standard Management
Stay on top of operations with: CLI, local GUI, SNMP, sFlow, RSPAN, single pane of glass NMS300
![](https://cdn.shopify.com/s/files/1/0571/8946/6289/t/7/assets/04-1655782953225.jpg?v=1655782968)
Secure Your Data
Defend with Access Control, DiffServ QoS policies, LACP Link Aggregation, Private VLANs, Denial of service protection
![](https://cdn.shopify.com/s/files/1/0571/8946/6289/t/7/assets/01-1655782953184.jpg?v=1655782955)
Dependable Operations
Enjoy high availability across virtual servers through load balancing and nonstop forwarding failover.
![](https://cdn.shopify.com/s/files/1/0571/8946/6289/t/7/assets/05-1655784543813.jpg?v=1655784545)
Specifications
Model Number
XSM4324CS
Ports
24 Ports Copper 100M / 1G / 10G. 4 Ports SFP+ 1G / 10G (shared)
1 Modular Bay with One (1) 250W Modular PSU included APS250W
480 Gps Switching Fabric
Fixed Fan Front-to-Back 37dB
Management Options
Ethernet: Out-of-band 1G port (Back)
Console: RJ45 RS232 (Back). Mini-USB (Front)
Storage: USB (Front)
Single-pane-of-glass NMS300 management platform with mass-configuration support
Dual firmware image and configuration file for updates with minimum service interruption
Table Sizes
128K MAC 8k ARP / NDP
Up to 960 Gbps
Throughput up to 714 Mpps
Application Static Routing- 64v4 / 64v6 RIP: 512 OSPF: 512
Latency
<0.9µs 10G SFP+
<1.25µs 10G RJ45
IP Multicast
1,024 IPv4 / 512 IPv6
Multicast IGMP Membership
2k IPv4 / IPv6
M4300 Series features
License-free L2 and Layer 3, Layer 4 with Policy Based Routing, RIP, VRRP, OSPF and PIM
VLANS: 4k with 2K DHCP Server Leases, IPv4: 256 Pools / IPV6: 16 Pools
Mix-and-match Stackable Managed Switch Platform with nonstop forwarding and failover on all 1Gb to 10Gb models
Pre-configured for AV-over-IP L2 Multicast on all models 10G models (SDVoE Ready)
Warranty
Lifetime Warranty
