VOLKTEK MEN-6412AB Managed Aggregation Switch with 4 FX/GbE Combo RJ45/SFP, 4 FX/GbE SFP, 4 GbE SFP Ports, Extl. Power Adapter and Battery Charger Function
SKU: MEN-6412AB
Product Highlights
- 4 x FX/GbE Combo RJ45/SFP ports, 4 x FX/GbE SFP ports, and 4 x SFP uplink ports for swift data communication
- 1 x Console Port for command-line interface and USB port supports firmware upgrades, saves configuration files and downloads log files
- Storm control and QoS prioritizes traffic to support efficient work
- A front power outlet deign for easy installation
- Operating temperatures -20°C~60°C (-4°F~140°F)
Features
Space-saving Design
Equipped with defense mechanisms such as ACL (Access Control List), DHCP (Dynamic Host Configuration Protocol) snooping, ARP (Address Resolution Protocol), IEEE 802.1X, and Port Security to deliver a stable and secure network.
Last-mile Protection
Equipped with Device Lock feature to lock the device to a specific network making it impossible to be reconfigured to work on a different network if it is stolen.
Efficient Network Monitoring and Management
SNMP (Simple Network Management Protocol) v1/v2c/v3 and RMON (Remote Monitoring) for real-time traffic analysis, remote-monitoring, and management.
Redundant Ring for Fast Network Recovery
Various ring protocols such as STP (Spanning Tree Protocol), RSTP (Rapid Spanning Tree Protocol), MSTP (Multiple Spanning Tree Protocol), Xpress Ring, and ERPS (Ethernet Ring Protection Switching) for recovery of network failure in milliseconds.
Efficient Traffic Prioritization
Effective QoS mechanisms for priority assignment, transmission of dedicated traffics to specific applications, and allocation of appropriate bandwidth to mission-critical communications.
Specifications
Standards
| IEEE 802.3 | 10BASE-T |
|---|---|
| IEEE 802.3u | 100BASE-TX |
| IEEE 802.3ab | 1000BASE-T |
| IEEE 802.3u | 100BASE-FX |
| IEEE 802.3z | 1000BASE-SX/LX |
| IEEE 802.3 | Nway Auto-negotiation |
| IEEE 802.3x | Flow Control |
| IEEE 802.3ad | Link Aggregation |
| IEEE 802.1AB | LLDP |
| IEEE 802.3az | Energy Efficient Ethernet (EEE) |
| IEEE 802.1AB | LLDP |
| IEEE 802.1ad | QinQ |
| IEEE 802.1D | STP |
| IEEE 802.1w | RSTP |
| IEEE 802.1s | MSTP |
| IEEE 802.1p | Class of Service |
| IEEE 802.1Q | VLAN Tagging |
| IEEE 802.1X | Port Authentication |
| IEEE 1588v2 | PTP |
Interface
| Ports | 4 x 100FX/GbE Combos
4 x 100FX/GbE SFP Slots 4 x GbE SFP Slots 1 x RJ45 Console Port 1 x USB Port |
|---|---|
| LED Panel | PWR1, PWR2, POST, ALM, 1000, LNK/ACT |
Power
| Input Voltage | DC Jack: 15V/4A AC Adapter
DC Terminal Block: 48V Dual Input Battery Terminal Block: 12V Battery AC Inlet: 100~240VAC,50/60Hz (MEN-6412C) |
|---|---|
| Power Consumption | System: 18W (max) |
Mechanical and Environment
| Housing | Metal Case |
|---|---|
| Mounting | Desktop, Rack Mount (Optional) |
| Operating Temperature | -20°C~60°C (-4°F~140°F)
- 20°C~50°C (-4°F~122°F) (For LVD Certification) |
| Storage Temperature | -40°C~70°C (-40°F~158°F) |
| Operating Humidity | 5 to 95% RH (non-condensing) |
| Storage Humidity | 5 to 95% RH (non-condensing) |
| Weight | 1.25 kg (2.75 lb) |
| Dimension (WxHxD) | 268 x 44 x 128 mm (10.6 x 1.7 x 5 in) |
Ordering Information
| Model | Description |
|---|---|
| MEN-6412 | Managed 4 x FX/GbE Combo RJ45/SFP & 4 x FX/GbE SFP & 4 x GbE SFP Switch with USB Support, w/ External Power Adapter |
| MEN-6412AB | Managed 4 x FX/GbE Combo RJ45/SFP & 4 x FX/GbE SFP & 4 x GbE SFP Switch with with USB Support, w/ External Power Adapter, Battery Charge Function Included |
| MEN-6412D | Managed 4 x FX/GbE Combo RJ45/SFP & 4 x FX/GbE SFP & 4 x GbE SFP Switch with with USB Support, w/ Internal DC Power |
| MEN-6412AD | Managed 4 x FX/GbE Combo RJ45/SFP & 4 x FX/GbE SFP & 4 x GbE SFP Switch with with USB Support, w/ Internal DC Power + External Power Adapter |
| MEN-6412C | Managed 4 x FX/GbE Combo RJ45/SFP & 4 x FX/GbE SFP & 4 x GbE SFP Switch with with USB Support, w/ AC Power Input (50°C) |
