VOLKTEK MEN-3510B 8 Ports GbE Managed Access Switch with 2 SFP Ports, Intl. AC Power and Battery Charger Function

SKU: MEN-3510B
VOLKTEK MEN-3510B 8 Ports GbE Managed Access Switch with 2 SFP Ports, Intl. AC Power and Battery Charger Function
VOLKTEK MEN-3510B 8 Ports GbE Managed Access Switch with 2 SFP Ports, Intl. AC Power and Battery Charger Function
VOLKTEK MEN-3510B 8 Ports GbE Managed Access Switch with 2 SFP Ports, Intl. AC Power and Battery Charger Function
VOLKTEK MEN-3510B 8 Ports GbE Managed Access Switch with 2 SFP Ports, Intl. AC Power and Battery Charger Function

VOLKTEK MEN-3510B 8 Ports GbE Managed Access Switch with 2 SFP Ports, Intl. AC Power and Battery Charger Function

SKU: MEN-3510B
/
Tax included. Shipping calculated at checkout.
  • Rated for use in Singapore
  • Local Service Center
  • Delivery options available
  • In stock
  • Inventory on the way
MEN-3510 is a managed 8-port, 10/100/1000 RJ45 downlink, and 2-port, FX/GbE SFP ports uplink, designed for broadband indoor office applications with basic needs in network infrastructure. The RJ45 type console port allows outbound network troubleshooting when networks go wrong. The USB port, designed to save configuration files, save system log files, and upgrade firmware, reduces network downtime and operational costs. This device is compatible with third-party devices and for scalable topologies. To keep regular internet speeds this device uses the Quality of Service (QoS) protocol to balance the use of bandwidth. It meets the requirements of triple-play broadband services along with low latency streaming - TV, internet, and phone. The management features allow safe, easy access and configuration of this device, using the web GUI and command line. It is designed to continue working during sudden power cuts with the help of an emergency battery parallel to the DC power jack input. To reduce the need for continuous maintenance, the fanless design of this switch avoids the accumulation of debris in the device, which also allows it to operate silently and hinder noise disturbances. The temperature operation of 0°C~50°C (32°F~122°F) allows for indoor network room in-rack or cabinet storage.

Customer Reviews

Be the first to write a review
0%
(0)
0%
(0)
0%
(0)
0%
(0)
0%
(0)
More from All Products
CADYCE CA-U34H USB 3.0 4-Port Hub
CADYCE CA-U34H USB 3.0 4-Port Hub
CADYCE CA-U34H USB 3.0 4-Port Hub
Enquire with us
Sold Out
HP Portable SSD P500 250GB/500GB/1TB
HP Portable SSD P500 250GB/500GB/1TB
HP P500 Portable SSD
Enquire with us
GOOBAY CAT 7 S/FTP PIMF RJ45 LSZH - Yellow
GOOBAY CAT 7 S/FTP PIMF RJ45 LSZH - Yellow
GOOBAY LAN CAT 7 S/FTP PIMF RJ45 LSZH Patch Cable - Yellow
Enquire with us
GOOBAY CAT 7 S/FTP PIMF RJ45 LSZH - Blue
GOOBAY CAT 7 S/FTP PIMF RJ45 LSZH - Blue
GOOBAY LAN CAT 7 S/FTP PIMF RJ45 LSZH Patch Cable - Blue
Enquire with us
Sold Out
Arlo Ultra 2 VMS5340 4K Ultra HD Wireless HDR Security Camera System
Arlo Ultra 2 VMS5340 4K Ultra HD Wireless HDR Security Camera System
ARLO Ultra 2 VMS5340 4K Ultra HD Wireless HDR Security Camera System
Enquire with us
GOOBAY LAN CAT 6 SOLID U/UTP WEISS CCA CPR
GOOBAY LAN CAT 6 SOLID U/UTP WEISS CCA CPR
GOOBAY LAN CAT 6 SOLID U/UTP WEISS CCA CPR
Enquire with us
Back to All Products
Datasheet
Product Highlights
  • 8 x 10/100/1000 RJ45 downlink ports for broadband office applications with basic needs in infrastructure
  • 2 x FX/GbE SFP uplink ports for long-distance connectivity and cascading and 1 x Console Port for command-line interface
  • Quality of Service (IEEE 802.1p) Protocol categorizes high priority traffic
  • A front power outlet deign for easy installation
  • Operating temperatures 0°C~50°C (32°F~122°F)
Features

Non-stop Network with Redundant Power

Powered by both AC and DC with battery backup option to ensure non-stop operation.

Extensive Security Features

Equipped with defense mechanisms such as ACL (Access Control List), DHCP (Dynamic Host Configuration Protocol) snooping, ARP (Address Resolution Protocol), IEEE 802.1X, and Port Security to deliver a stable and secure network.

Efficient Traffic Prioritization

Effective QoS mechanisms for priority assignment and transmission of dedicated traffics to specific applications.

Efficient Network Monitoring and Management

SNMP (Simple Network Management Protocol) v1/v2c/v3 and RMON (Remote Monitoring) for real-time traffic analysis, remote monitoring, and management.

Rapid Ring for Fast Network Recovery

Industrial ring capable of switching a faulty link to the redundant link in milliseconds.

Specifications

Standards

IEEE 802.310BASE-T
IEEE 802.3u 100BASE-TX
IEEE 802.3ab1000BASE-T
IEEE 802.3u 100BASE-FX
IEEE 802.3z 1000BASE-SX/LX
IEEE 802.3Nway Auto-negotiation
IEEE 802.3x Flow Control
IEEE 802.3ad Link Aggregation
IEEE 802.3azEnergy Efficient Ethernet (EEE)
IEEE 802.1ABLLDP
IEEE 802.1DSTP
IEEE 802.1wRSTP
IEEE 802.1pClass of Service
IEEE 802.1QVLAN Tagging
IEEE 802.1XPort Authentication

Interface

Ports8 x 10/100/1000BASE-T RJ45 Ports
2 x 100FX/GbE SFP Slots
1 x RJ45 Console Port
LED PanelPWR, ALM, POST, 1000, LNK/ACTPWR, ALM, POST, 1000, LNK/ACT

Power

Input VoltagePrimary inputs: AC 100~240VAC 50~60Hz,
15V DC Power Adapter
Redundant inputs: 12V Battery
Power Consumption 10W (System)

Mechanical and Environment

HousingMetal Case
MountingRack Mount
Operating Temperature 0°C~50°C (32°F~122°F)
Storage Temperature -20°C~70°C (-4°F~158°F)
Operating Humidity 10 to 95% RH (non-condensing)
Storage Humidity5 to 95% RH (non-condensing)
Weight1.17 kg (2.58 lb)
Dimension (WxHxD)268 x 44 x 128 mm (10.6 x 1.7 x 5 in)

Ordering Information

ModelDescription
MEN-3410 Managed 8 x 10/100/1000 RJ45 & 2 x FX/GbE SFP Switch, w/ Internal AC Power
MEN-3410BManaged 8 x 10/100/1000 RJ45 & 2 x FX/GbE SFP Switch, w/ Internal AC Power, Battery Charge Function Included
MEN-3410DManaged 8 x 10/100/1000 RJ45 & 2 x FX/GbE SFP Switch, w/ Internal DC Power
MEN-3410ABManaged 8 x 10/100/1000 RJ45 & 2 x FX/GbE SFP Switch, w/ External AC Power Adapter, Battery Charge Function Included
MEN-3510Managed 8 x 10/100/1000 RJ45 & 2 x FX/GbE SFP Switch, w/ Internal AC Power
MEN-3510BManaged 8 x 10/100/1000 RJ45 & 2 x FX/GbE SFP Switch, w/ Internal AC Power, Battery Charge Function Included
