VOLKTEK GPI-431 GbE PoE+ 60W Injector with PD Detection

SKU: GPI-431
VOLKTEK GPI-431 GbE PoE+ 60W Injector with PD Detection
VOLKTEK GPI-431 GbE PoE+ 60W Injector with PD Detection
VOLKTEK GPI-431 GbE PoE+ 60W Injector with PD Detection
VOLKTEK GPI-431 GbE PoE+ 60W Injector with PD Detection

VOLKTEK GPI-431 GbE PoE+ 60W Injector with PD Detection

SKU: GPI-431
/
Tax included. Shipping calculated at checkout.
  • Rated for use in Singapore
  • Local Service Center
  • Delivery options available
  • In stock
  • Inventory on the way
GPI-431 is a single port, 60W (IEEE 802.3 bt) Power Injector for remote PoE++ devices. This device is a simple and inexpensive solution for Powered Devices in remote areas or at locations where there is no power sourcing equipment. It withstands temperatures between  0°C-40°C (32°F-104°F). It uses LED indicators to show when the device is in operation. By generating up to 60W, GPI-431 supplies remote power for modern applications such as dome surveillance cameras, lights and smart kiosks.

Customer Reviews

Be the first to write a review
0%
(0)
0%
(0)
0%
(0)
0%
(0)
0%
(0)
More from All Products
CADYCE CA-U34H USB 3.0 4-Port Hub
CADYCE CA-U34H USB 3.0 4-Port Hub
CADYCE CA-U34H USB 3.0 4-Port Hub
Enquire with us
Sold Out
HP Portable SSD P500 250GB/500GB/1TB
HP Portable SSD P500 250GB/500GB/1TB
HP P500 Portable SSD
Enquire with us
GOOBAY CAT 7 S/FTP PIMF RJ45 LSZH - Yellow
GOOBAY CAT 7 S/FTP PIMF RJ45 LSZH - Yellow
GOOBAY LAN CAT 7 S/FTP PIMF RJ45 LSZH Patch Cable - Yellow
Enquire with us
GOOBAY CAT 7 S/FTP PIMF RJ45 LSZH - Blue
GOOBAY CAT 7 S/FTP PIMF RJ45 LSZH - Blue
GOOBAY LAN CAT 7 S/FTP PIMF RJ45 LSZH Patch Cable - Blue
Enquire with us
Sold Out
Arlo Ultra 2 VMS5340 4K Ultra HD Wireless HDR Security Camera System
Arlo Ultra 2 VMS5340 4K Ultra HD Wireless HDR Security Camera System
ARLO Ultra 2 VMS5340 4K Ultra HD Wireless HDR Security Camera System
Enquire with us
GOOBAY LAN CAT 6 SOLID U/UTP WEISS CCA CPR
GOOBAY LAN CAT 6 SOLID U/UTP WEISS CCA CPR
GOOBAY LAN CAT 6 SOLID U/UTP WEISS CCA CPR
Enquire with us
Back to All Products
Datasheet
Product Highlights
  • 1 x 10/100/1000 Base-T RJ45 port
  • 1 x 10/100/1000 Base-T PSE port
  • 60W PoE++ (IEEE 802.3 bt) Power Injection
  • LED Indication (Power Transmission)
  • Operating Temperature 0°C-40°C (32°F-104°F)
Features
  • One 10/100/1000Base-Tport
  • 4-Pair 60W PoE (Power/Data)
  • Automatic detection of connected PoE devices
  • Compliant with IEEE802.3, 802.3u, 802.3ab, 802.3af, 802.3at standards
  • IEEE 802.3af/at backward compatible
  • Full-range (100-240VAC) internal power supply
  • No Fan, natural cooling, small size, no noise
  • CE/FCC compliant
Specifications

Interface

Ports1 x 10/100/1000 Base-T RJ45 port ,  1 x 10/100/1000 Base-T PSE port (60W)
LED Panel Mode A, Mode B, Power

Power

Input Voltage 56V DC Max.
User Port Power 60W Max.
Input Power Voltage and Frequency 100-240V AC, 50 to 60 Hz

Mechanical and Environment

Operating Ambient Temperature 0°C~40°C (32°F~104°F)
Weight 530 g (1.17 lb)
Dimension (WxHxD) 180 x 71 x 37 mm (7.08 x 2.80 x 1.46 in)

Ordering Information

ModelDescription
GPI-431 GbE PoE+ 60W Injector with PD Detection
