• 20 x FX/GbE SFP, 4 x FE/GbE Combo RJ45/SFP ports, 4 x multi-rate GbE/10G SFP+ uplink ports for ring topology and redundancy
• The multi-rate ports allow to reduce CapEx offering two available speeds 1Gb and 10G
• 1 x Console Port for command-line interface and USB port supports firmware upgrades, saves configuration files and downloads log files
• Quick troubleshooting to identify the interface errors through cable test and DDMI functions
• Operating temperatures 0°C~60°C (32°F~140°F)

10G Uplink Interface

4 slots SFP+ for 1G/10G fiber uplinks can deliver wire-speed throughput with low latency for data-intensive application. 10G networking is less expensive than highly specialized Fiber Channel (SAN) and do not needs a specialized skill set for installation and management. To compare with aggregating multiple Gigabit Ethernet links, it can help reducing the cost and increasing manageability efficiently.

Multicast Video Service Support

Equipped with Device Lock feature to lock the device to a specific network making it impossible to be reconfigured to work on a different network if it is stolen.

Redundant Ring for Fast Network Recovery

Even a few seconds of missed communications due to link failures can cause inconvenience, and recovery can become critical. Volktek's proprietary Xpress Ring in Atthis-6500 Series rapidly reacts to such link failures and recovers in less than 50ms, a much faster fail-over time to support nonstop transmissions. This is critical for networks handling heavy video and data traffic. In addition, ERPS, Dual Homing, LACP and RSTP/MSTP provide a highly reliable network with redundancy connections whenever required and guarantee continuous network uptime.

Efficient Traffic Prioritization

Network applications need different levels of services delivered to them reliably without any transmission delays and interruptions. The Atthis-6500 Series has comprehensive QoS mechanisms that assign priority to applications and send only specific dedicated traffic to them. In addition, bandwidth management functions of the switch allocate greater bandwidth for mission-critical communications. With increased control, administrators can prevent unpredictable errors and utilize the bandwidth more effectively.

Enhanced Control and Security

The Atthis-6500 Series implements several defense mechanisms such as ACL, DHCP snooping, ARP, IEEE 802.1X and Port Security to deliver robust network security and enables service providers to offer more stable services on a more secure network.

Efficient Network Monitoring and Management

It is designed with SNMP (Simple Network Management Protocol) v1/v2c/v3 and RMON (Remote Monitoring) for real-time traffic analysis, flexible network management and monitoring options which increased efficiency and performance. Whether managing from an 'in-band' SNMP management station or Internet web browser, or 'outof-band' on console port, the 6500 series makes network monitoring and troubleshooting easy. SNMP is used for collecting information from, and configuring, network devices on an Internet Protocol (IP) network. Volktek Managed switch provides SNMP agent that works with third-party SNMP management software to monitor the device status.
