• 24 x 10/100/1000 RJ45 & 2 x FX/GbE SFP uplink ports for ring topology and redundancy
• 2 x FX/GbE dual rate SFP uplink ports for long-distance connectivity
• Ideal for connectivity in commercial properties and perimeter security applications
• Fanless design for silent operation also avoids the accumulation of debris in the device
• Operating temperatures 0°C~50°C (32°F~122°F)

Faster Data Transmissions

Providing faster data transmissions over the network is no longer a difficult task to service providers. Atthis 5100-24GT2GS offers a best solution to improve the responsiveness of applications and increase file transfer speeds with its features that deliver high performance. Its high port density provides a 52Gbps non-blocking switching capacity that reduces transmission bottlenecks and increases the bandwidth. Service providers can create a high-performance network infrastructure using Atthis 5100-24GT2GS and fuel their businesses.

Multicast Video Service Support

Deploying multicast applications such as IPTV has never been easier than before with comprehensive multicast traffic functions, IGMP snooping and MVR, in Atthis 5100-24GT2GS. IGMP snooping regulates multicast traffic in a given VLAN and MVR operates with hosts on different VLANs in a Layer 2 network. These features on isolate the multicast streams and significantly reduce traffic from streaming media and other bandwidth-intensive IP multicast applications for better bandwidth. Thereby, Atthis 5100-24GT2GS supports applications that use multi-traffic in large scale across the network, saves network bandwidth, reduces operational burden and enhances the overall network performance.

Comprehensive QoS Mechanisms to Assign Priority

Network applications need different levels of services delivered to them reliably without any transmission delays and interruptions. Atthis 5100-24GT2GS has comprehensive QoS mechanisms that assign priority to applications and send only specific dedicated traffic to them. In addition, bandwidth management functions of the switch allocate greater bandwidth for mission-critical communications. With increased control, administrators can prevent unpredictable errors and utilize the bandwidth more effectively.

Robust Network Security

Atthis 5100-24GT2GS implements complete Layer 2 to Layer 4 ACLs to restrict access to your sensitive network resources by filtering specific packets based on TCP/UDP ports, source and destination IP addresses or particular network devices. Furthermore, DHCP snooping, ARP Inspection, IEEE 802.1X and Port Security provide additional tools to manage access and levels of use of network. These defence mechanisms of Atthis 5100-24GT2GS deliver robust network security and enables service providers to offer more stable services on a more secure network.

Efficient Network Monitoring and Management Tools

Issues that impact network performance can be quickly identify with enhanced traffic management, monitoring and analysis tools including SNMP and RMON. Designed to improve management efficiency, SNMP allows end users to centrally manage different levels in a network and RMON gives the capability to monitor the network performance. Service providers can ensure a reliable network by identifying connectivity and performance issues, and isolating the problem remotely on individual switches. This avoids high OPEX and manage a healthy and efficient network.

Fine-grained Service Management

Beside basic port-based VLAN function, Atthis 5100-24GT2GS provides higher and flexible levels of VLAN configuration related to MAC and Protocol-based. While MAC-based comprises of defining a virtual network according to the MAC addresses of stations, the Protocol-based VLAN makes it possible to create a virtual network by protocol type. These features along with VLAN stacking enable ISPs to flexibly deliver services with extra security and separation. As a result, ISPs using Atthis 5100-24GT2GS can experience fine-grained service management fulfilling the requirements of their subscribers.

Delivers Enhanced Ring/Path Redundancy and Bandwidth Aggregation

Short spans of missed communication due to link failures can have a negative impact on the network. Recovery and redundancy features are critical for networks handling heavy video and data traffic. Dual Homing, LACP and RSTP provide a highly reliable network with redundancy connections whenever required and guarantee continuous network uptime.

Standards

Interface

Power

Mechanical and Environment

Ordering Information
