MAX Transit Duo Pro

Redefining Pro

Wait no more, experience the new fast

Why settle for less advanced Wi-Fi, throughput and SpeedFusion speed?
Experience it all, but faster with Wi-Fi 6!

It’s got the power!

Achieve non-stop power for fixed deployments or on-the-go mobile deployments with duo USB-C power bank input ports. Equipped with a Micro-Fit power connector to secure your power source, ensuring that your device remains powered on with no outage. Believe it’s got the power!

Poor connectivity? No problem!

A simple connection to SpeedFusion Cloud keeps your connection unbreakable. With intricately placed endpoints globally, it ensures you remain connected wherever you are.

Elevate the way you manage SIMs

Elevate the way you manage SIMs with eSIM support and sophisticated hardware like the SIM Injector. Manage SIMs more efficiently from anywhere, at any time.

Safeguard your applications

MAX Transit Duo Pro offers flexibility in the ways you can create SpeedFusion VPN tunnels, enabling 256-bit AES Encryption to ensure your applications are kept protected, so that you can browse with confidence.

Running applications just got easier!

Want to run third party applications directly with your MAX Transit Duo Pro? Well now you can! With edge computing Docker and Python*, the possibilities are endless!

* Available in firmware 8.3.0.

Bundle Offer

Receive a complimentary SpeedFusion Connect Pack with the purchase of any additional PrimeCare plan (available in 2 or 4 year options).^ The SFC Pack includes SFC Protect and a bucket of SFC LTE/5G with global access.

^ Contact your reseller for more information.
# The SFC pack includes 2.5TB SFC Protect and 30GB SFC 5G/LTE

Ports and Connections

^ Requires a PrimeCare subscription, complimentary for the first year.
@ IPsec VPN supports connection with Cisco, Juniper, Peplink, or Pepwave devices.
* Certification pending.

Software

• Pepwave MAX Firmware

WAN

• Support for PPPoE, Static IP, DHCP
• WAN Link Health Check
• Bandwidth Allowance Monitor
• Support for Dynamic DNS services
• IPv6 Support

LAN

• DHCP Server for LAN Clients
• Extended DHCP Option
• DHCP Reservation
• DNS Proxy for LAN Clients
• VLAN on LAN Support

Load Balancing

• Intelligent Failover
• Session Persistence
• Per-Service Load Distribution
• Multiple Algorithms
  -Weighted Balance
  - Priority
  - Overflow
  - Persistence
  - Least Used
  - Lowest Latency
  - Enforced
  - Fastest Response Time

Complete VPN Solution

• SpeedFusion VPN
• SpeedFusion
  – Site
  - to-Site VPN
  – SpeedFusion Hot Failover^
  – SpeedFusion WAN Smoothing^
  – SpeedFusion Bandwidth Bonding^
  – 256-bit AES Encryption
  – Pre-shared Key Authentication
  – Dynamic Routing – PPTP VPN Server – RADIUS, LDAP Authentication
• IPsec VPN (Network-to-Network)

Networking

• NAT and IP Forwarding
• Static Routes
• Port Forwarding
• Many to One, One to One NAT
• NAT Pool
• SIP ALG, H.323 ALG
• UPnP, NAT-PMP
• WINS Server

Security

• 128-bit WEP
• WPA & WPA 2
• Stateful Firewall
• DoS Prevention
• Web Blocking

Advanced QoS

• Individual Bandwidth Limit
• Application Prioritization
  - SIP, HTTPS, VPN QoS
  - Custom Application QoS

AP Controller

• AP Controller Support
• Wi-Fi Usage Statistics

Global Positioning System

• Integrated GPS
• Device Location Map
• Location Tracking Data with InControl 2
• Fleet Management with InControl 2

Captive Portal Support

• Support for Wired and Wireless LAN Clients
• Support RADIUS Authentication
• Time and Usage Quotas on Open Access Mode
• Built-in Customizable Splash Page
• Social Wi-Fi Hotspot support
• External Captive Portal support

Certifications

• FCC, CE, RoHS, IC
• E-Mark*
• EN 61373:1999 IEC 61373:1999 Shock and Vibration Resistance
• EN 50155 Railway Applications – Electronic Equipment used on Rolling Stock
• EN 61000 Electromagnetic Compatibility

Device Management

• Web Administrative Interface
• Command Line Interface
• InControl Cloud Management
• Email Notification
• Active Client and Session Lists
• Bandwidth Usage Statistics
• Syslog Service
• SNMP v1, v2c and v3

Embedded Modems

• 2x CAT-12

LTE Bands

• B1, B2, B3, B4, B5, B7, B8, B12, B13, B14, B17, B18, B19, B20, B25, B26, B28, B29, B30, B38, B39, B40, B41, B42, B43, B48, B66, B71

3G Bands

• B1, B2, B4, B5, B8, B9, B19

Package Content

• MAX Transit Duo Pro
• 4x LTE Antennas (ACW-234)
• 2x Wi-Fi Dual Band Antenna (ACW-341)
• 1x GPS Active Antenna (ACW-232)
• 1x 12V 2A 4 Pin Power Supply (ACW-632)
• 1x 6 Pin Terminal Block Connector
• 1 Pair of Mounting Brackets (ACW-724)
