Sail Away but Stay Close and Connected

With the Dome Pro LR, maritime connectivity reaches new heights and extends over greater distances. Housing dual 5G modems and high-gain antennas to support virtually any band around the world, the Dome Pro LR achieves reliable long range outdoor connectivity with reported ranges of over 25 miles / 40 kilometers* from the coastline. *Range may vary depending on the deployment environment

Fit Anywhere, Bond Any WAN

Use the Dome Pro LR’s Wi-Fi as WAN support to leverage existingWi-Fi networks for another source of connectivity.

Pair the Wi-Fi and dual 5G connections with an added Starlink or VSAT link using SpeedFusion’s Bandwidth Bonding for higher reliability, or experience no more interruptions with Hot Failover.

Seamless Deployment

The Dome Pro LR combines a router and integrated antennas within a single enclosure, ensuring minimal cable loss and delivering optimal performance. Additionally, powering it up is made convenient with just a single cable.

Use its PoE functionality to conveniently add Peplink PoE routers or add access points for wider Wi-Fi coverage. Alternatively, eliminate the need for additional hardware and use the Dome Pro LR’s PoE output on 802.3at powered devices such as IP cameras.

Look no further than Peplink to complete your solution. The Dome Pro LR’s dual Ethernet ports enable you to scale up your deployment with an additional WAN source, such as Starlink or VSAT.

Benefits

Cost-efficient installations and improved uptime for a safer voyage

Seamless connectivity to stay in touch with family and friends

24/7 internet access for uninterrupted viewing of your favorite shows

Access to functional connectivity even in the most remote rural areas

* IPsec VPN supports connection with Cisco, Juniper, Peplink, or Pepwave devices.

Software

• Peplink MAX Firmware

WAN Cellular

• Support for PPPoE, Static IP, DHCP
• WAN Link Health Check
• Bandwidth Allowance Monitor
• Support for Dynamic DNS services
• WAN Port Convertible into LAN Port

LAN

• DHCP Server for LAN Clients
• Extended DHCP Option
• DHCP Reservation
• DNS Proxy for LAN Clients
• VLAN on LAN Support

Load Balancing

• Intelligent Failover
• Session Persistence
• Per-Service Load Distribution
• Multiple Algorithms
  - Weighted
  – Enforced
  – Persistence
  – Priority
  – Overflow
  – Least Used
  – Lowest Latency
  – Fastest Response Time


Complete VPN Solution

• SpeedFusion VPN
• SpeedFusion
  – Site-to-Site VPN
  – SpeedFusion Hot Failover
  – SpeedFusion WAN Smoothing
  – SpeedFusion Bandwidth Bonding
  – 256-bit AES Encryption
  – Pre-shared Key Authentication
  – Dynamic Routing
  – X.509 Certificate Support
  – PPTP VPN Server
  – RADIUS, LDAP Authentication

  IPsec VPN (Network-to-Network) *


Networking

• NAT and IP Forwarding
• Static Routes
• Port Forwarding
• Many to One, One to One NAT
• NAT Pool
• SIP ALG, H.323 ALG
• UPnP, NAT-PMP
• WINS Server
• VRRP HA support

Security

• Stateful Firewall
• DoS Prevention
• Web Blocking

Advanced QoS

• User Groups
• Bandwidth Reservation
• Individual Bandwidth Limit
• Application Prioritization
• By User Groups
• SIP, HTTPS, VPN QoS
• Custom Application QoS

AP Controller

• AP Controller Standard type
• Support for Pepwave AP Series
• Auto AP Discovery
• Auto AP Firmware Management
• AP Profile Configuration
• Wi-Fi Usage Statistics

Global Positioning System

• Integrated GPS
• Device Location Map
• Location Tracking Data with InControl 2
• Fleet Management with InControl 2

Captive Portal Support

• Support for Wired and Wireless LAN Clients
• Support RADIUS Authentication
• Time and Usage Quotas on Open Access Mode
• Built-in Customizable Splash Page
• Social Wi-Fi Hotspot support
• External Captive Portal support

Device Management

• Web Administrative Interface
• Command Line Interface
• InControl Cloud Management
• Email Notification
• Active Client and Session Lists
• Bandwidth Usage Statistics
• Syslog Service
• SNMP v1, v2c and v3

Embedded Modems

• 2x 5G

5G Bands

• 5G (SA & NSA) Sub 6Ghz: n1, n2, n3, n5, n7, n8, n12, n13, n14, n18, n20, n25, n26, n28, n29, n30, n38, n40, n41, n48, n66, n70, n71, n75, n76, n77, n78, n79

LTE Bands

• B1, B2, B3, B4, B5, B7, B8, B12, B13, B14, B17, B18, B19, B20, B25, B26, B28, B29, B30, B32, B34, B38, B39, B40, B41, B42, B43, B46, B48, B66, B71

Package Content

• 1x Dome Pro LR
• 4x M8 bolts
• 2x Waterproof Ethernet Adapters (ACW-112)
