NETGEAR XSM4316PA 16-Port Fully Managed Switch M4300-8X8F, 16x10G, 8x10GBASE-T

SKU: XSM4316PA-100AJS
NETGEAR 16-Port Fully Managed Switch M4300-8X8F, 16x10G, 8x10GBASE-T, 8xSFP+, Half-Width Stackable, ProSAFE Lifetime Protection (XSM4316S) NETGEAR 16-Port Fully Managed Switch M4300-16X — Half-Width Stackable Managed Switch with 16X 10G / 199W PoE+ Budget ProSAFE Lifetime Protection (XSM4316PA)
NETGEAR XSM4316PA 16-Port Fully Managed Switch M4300-8X8F, 16x10G, 8x10GBASE-T
NETGEAR XSM4316PA 16-Port Fully Managed Switch M4300-8X8F, 16x10G, 8x10GBASE-T
NETGEAR XSM4316PA 16-Port Fully Managed Switch M4300-8X8F, 16x10G, 8x10GBASE-T
NETGEAR 16-Port Fully Managed Switch M4300-8X8F, 16x10G, 8x10GBASE-T, 8xSFP+, Half-Width Stackable, ProSAFE Lifetime Protection (XSM4316S) NETGEAR 16-Port Fully Managed Switch M4300-16X — Half-Width Stackable Managed Switch with 16X 10G / 199W PoE+ Budget ProSAFE Lifetime Protection (XSM4316PA)
NETGEAR XSM4316PA 16-Port Fully Managed Switch M4300-8X8F, 16x10G, 8x10GBASE-T
NETGEAR XSM4316PA 16-Port Fully Managed Switch M4300-8X8F, 16x10G, 8x10GBASE-T
NETGEAR XSM4316PA 16-Port Fully Managed Switch M4300-8X8F, 16x10G, 8x10GBASE-T

NETGEAR XSM4316PA 16-Port Fully Managed Switch M4300-8X8F, 16x10G, 8x10GBASE-T

SKU: XSM4316PA-100AJS
/
Tax included. Shipping calculated at checkout.
  • Rated for use in Singapore
  • Local Service Center
  • Delivery options available
  • In stock
  • Inventory on the way

The NETGEAR® M4300 Stackable Switch Series delivers L2/L3/L4 and IPv4/IPv6 cost-effective services for mid-enterprise edge and SMB core deployments with unrivalled ease of use: 10/40 Gigabit models can seamlessly stack with 1 Gigabit models within the series, enabling spine and leaf line-rate topologies.

Nonstop forwarding (NSF) virtual chassis architectures provide advanced High Availability (HA) with hitless failover across the stack. Intelligent NETGEAR IGMP Plus™ multicast allows for scalable Pro AV installations at Layer 2 without the PIM complexity. Dual redundant, modular power supplies equipping full width models contribute to business continuity management. Layer 3 feature set includes static, dynamic and policy-based routing – as standard.

The NETGEAR M4300 Switch Series is perfect for wireless access, unified communications and professional AV-over-IP installations. NETGEAR Intelligent Edge Switch solutions combine latest advances in hardware and software engineering for higher flexibility, lower complexity and stronger investment protection, at a high value price point

Customer Reviews

No reviews yet
0%
(0)
0%
(0)
0%
(0)
0%
(0)
0%
(0)
More from All Products
CADYCE CA-U34H USB 3.0 4-Port Hub
CADYCE CA-U34H USB 3.0 4-Port Hub
CADYCE CA-U34H USB 3.0 4-Port Hub
Enquire with us
Sold Out
HP Portable SSD P500 250GB/500GB/1TB
HP Portable SSD P500 250GB/500GB/1TB
HP P500 Portable SSD
Enquire with us
GOOBAY CAT 7 S/FTP PIMF RJ45 LSZH - Yellow
GOOBAY CAT 7 S/FTP PIMF RJ45 LSZH - Yellow
GOOBAY LAN CAT 7 S/FTP PIMF RJ45 LSZH Patch Cable - Yellow
Enquire with us
GOOBAY CAT 7 S/FTP PIMF RJ45 LSZH - Blue
GOOBAY CAT 7 S/FTP PIMF RJ45 LSZH - Blue
GOOBAY LAN CAT 7 S/FTP PIMF RJ45 LSZH Patch Cable - Blue
Enquire with us
Sold Out
Arlo Ultra 2 VMS5340 4K Ultra HD Wireless HDR Security Camera System
Arlo Ultra 2 VMS5340 4K Ultra HD Wireless HDR Security Camera System
ARLO Ultra 2 VMS5340 4K Ultra HD Wireless HDR Security Camera System
Enquire with us
GOOBAY LAN CAT 6 SOLID U/UTP WEISS CCA CPR
GOOBAY LAN CAT 6 SOLID U/UTP WEISS CCA CPR
GOOBAY LAN CAT 6 SOLID U/UTP WEISS CCA CPR
Enquire with us
Back to All Products
SpecificationsProduct DatasheetInstallation Guide

Features

High Availability (HA)

Non-stop forwarding (NSF) virtual chassis architectures with hitless failover across the stack

Multi-Resiliency

Stacking and distributed link aggregation allow for zero downtime and load balancing capabilities

PVST+ Interoperability

Per VLAN Spanning Tree and Per VLAN Rapid Spanning Tree (PVSTP/PVRSTP)

Link Dependency

Enables or disables ports based on link state of different ports

Advanced IPv4/IPv6 security

Malicious code detection, DHCP Snooping, IP Source Guard protection and DoS attacks mitigation

299W PSU

Ships with 299W PSU APS299W installed Optional 600W PSU APS600W

Specifications

Product Number

XSM4316PA

Hardware Specifications

Power over Ethernet PoE : 16x 10GBASE-T PoE+

Fully provisioned for up to 30 Watts Per Port

199 Watts Total PoE+ Budget

Hardware Specifications : 16 Ports RJ45 PoE+ Multi-Gigabit 100M/ 1G / 2.5G / 5G / 10G

1 Modular Bay with 1 299W Modular PSU included APS299W (or 500W Budget with optional APS600W PSU)

1-unit 1U / 2-unit 1U Rack Mount (Included)

320 Gbps Switching Fabric

Fixed Fan Front-to-Back 35db

Management Options : Ethernet: Out-of-band 1G port (Back)

Console: RJ45 RS232 (Back)

Console: Mini-USB (Front)

Storage: USB (Front)

Single-pane-of-glass NMS300 management platform with mass-configuration support

Dual firmware image and configuration file for updates with minimum service interruption

Software Features

Table Sizes : 16K MAC 888ARP / NDP. Up to 480 Gbps. Throughput up to 357 Mpps

Application Static Routing- 64v4 / 64v6 RIP :
512 OSPF: 512

Latency : 2.76us 10G RJ45

IP Multicast : 96 IPv4 / 32 IPv6

Multicast IGMP Membership : 2k IPv4 / IPv6

M4300 Series features : License-free L2 and Layer 3, Layer 4 with Policy Based Routing, RIP, VRRP, OSPF and PIM

VLANS: 4k with 2K DHCP Server Leases, IPv4: 256 Pools / IPV6: 16 Pools

Mix-and-match Stackable Managed Switch Platform with nonstop forwarding and failover on all 1Gb to 10Gb models

Pre-configured for AV-over-IP L2 Multicast on all models 10G models (SDVoE Ready)

Warranty

Limited Lifetime Warranty
