Features
Copper Ethernet 5-speed ports that provide either Fast Ethernet, 1-Gigabit, 2.5-Gigabit, 5-Gigabit or 10-Gigabit connectivity
1 SFP+ Fiber port with 1-Gigabit or 10-Gigabit connectivity
Gives the exact speed required, no downgrade. Automatically detects which speed is needed by the connected device and provides the adequate speed
Can be connected with regular Cat5E Ethernet cables, without the need to upgrade to Cat6 wiring, therefore reducing wiring costs and hassle
Specifications
Product Number
GS110MX
100M/1G/2.5G/5G/10G RJ-45 copper ports
2
10M/100M/1G Copper ports
8
Form Factor
Desktop/Wall-Mount/Rackmount
Packet buffer memory
128KB
Bandwidth
56Gbps
MAC Address database size
16K
Number of priority queues
8
Jumbo Frame Support
Up to 9K packet size
Fan(s)
0 ( Fanless)
IEEE 802.3az
(Energy Efficient Ethernet)
Yes
Max power consumption (Watts)
13.2W
LEDs
Power,Fan, Speed, Link/Activity
Acoustic noise level @ 25° C (dBA)
0
Operating Temperature
0 ~ 40° C
Electromagnetic compliance
(A or B)
B
Dimensions (W x D x H)
236 x 102 x 27 mm (9.29 x 4.02 x 1.06 in)
Weight
0.74 kg (1.63 lbs)
Warranty Information
Limited Lifetime Hardware Warranty
