Features
Traffic Management
Auto Negotiation of speed and duplex modes
802.3x Flow Control
DHCP Client
Dynamic MAC address management
IEEE 802.1Q-based or port-based VLAN
QoS based on WRR, strict priority, or both
Port-based and IEEE 802.1p-based QoS
QoS based on ToS (Type-of-Service)
DSCP Support (GS105E and GS105PE only)
Rate Limiting
Link Aggregation / Port Trunking (Static LAGs on 16 ports and 24 ports, Static LAGs and LACP on 48 ports)
Switch Management
Switch discovery on MAC or PC using the NETGEAR Switch Discovery Tool
Advanced configuration and management using web browser-based GUI
Manage or deploy multiple switches using ProSAFE Plus Utility (requires Windows PC)
Firmware upgrade thru ProSAFE Plus Utility (TFTP) or web browser-based GUI
Configuration upload (to Server)
System password protection
Multi-language support (varies by model, see datasheet for specifics)
Specifications
Product Number
GS108PE-300EUS
Gigabit Ports
8
10 Gbps Port
n/a
Number of PoE/PoE+ ports
4
Total PoE Power budget (Watts)
53
Max MAC entries
4K
Buffer size
192KB
VLAN (Number Supported)
32
Number of LAGs & number of members
n/a
Supported Mulitcast groups
128
Max number of source ports allowed (many to 1)
7
Internal/External
External
Input: 48V/1.25A
Max consumption (Watts)
.0W (no PoE) / 60.0W (w/PoE max)
FAN
No
Acoustic Noise Level @25C (dBA)
0
Operating Temperature
0° to 50° C
MTBF (hrs)
1,242,394 hrs
Electromagnetic Compliance (A or B)
A
Physical Specifications
Weight (kg) : 0.54Kg
Dimensions (WxDxH) mm : 158x101x29
Warranty
Limited Lifetime Warranty
