Connection, type
RJ45 male (8P8C)
Connection 2, type
RJ45 male (8P8C)
Kink protection
both sides
Latch protection
both sides
Connection, shielding
yes
Connection, contact material
gold-plated 50µm
Contacting
EIA/TIA-568B
Specification
CAT 7
Cable type
Cat 7 raw cable
Shielding class
S/FTP (PiMF)
Number of shieldings
2 x
Type 1, shielding
foil (alu) PiMF
Type 2, shielding
braid (alu) overall shield
AWG
26/7 (stranded)
Inner conductor material
CU (copper)
Material cable sheath
LSZH
Cable sheath diameter (approx.)
6.2 mm
bending radius >
48 mm
LSZH compliant
yes
Cable length
1 m
max. bandwidth
500 MHz
Color
magenta
Special feature
Length indication on connector
Operating temperature from
-20 °C
Operating temperature up to
65 °C
Packaging type
Bulk
Warranty
1 year
Weight
44g
