Name: NETGEAR MS510TXUP 8-Port Multi-Gigabit/10G Ethernet Ultra60 PoE++ Smart Switch with 2 SFP+ Ports
Brand: Kaira Global (Singapore)
SKU: MS510TXUP-100EUS
Price: 1569.0 SGD
Availability: OutOfStock

NETGEAR MS510TXUP 8-Port Multi-Gigabit/10G Ethernet Ultra60 PoE++ Smart Switch with 2 SFP+ Ports

Sulfix

-100EUS

-100AJS

Price

Tax included. Shipping calculated at checkout.

Quantity

Rated for use in Singapore
Local Service Center
Delivery options available
In stock
Inventory on the way

[{"id":42833655857329,"title":"-100EUS","option1":"-100EUS","option2":null,"option3":null,"sku":"MS510TXUP-100EUS","requires_shipping":true,"taxable":true,"featured_image":null,"available":false,"name":"NETGEAR MS510TXUP 8-Port Multi-Gigabit\/10G Ethernet Ultra60 PoE++ Smart Switch with 2 SFP+ Ports - -100EUS","public_title":"-100EUS","options":["-100EUS"],"price":156900,"weight":2510,"compare_at_price":0,"inventory_management":"shopify","barcode":"606449152395","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":42833655890097,"title":"-100AJS","option1":"-100AJS","option2":null,"option3":null,"sku":"MS510TXUP-100AJS","requires_shipping":true,"taxable":true,"featured_image":null,"available":false,"name":"NETGEAR MS510TXUP 8-Port Multi-Gigabit\/10G Ethernet Ultra60 PoE++ Smart Switch with 2 SFP+ Ports - -100AJS","public_title":"-100AJS","options":["-100AJS"],"price":156900,"weight":2510,"compare_at_price":0,"inventory_management":"shopify","barcode":"606449152401","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}]

Provides 4 ports 1G/2.5G and 4 ports multi-gig/10G with 2 dedicated 10 Gigabit fiber ports for WiFi 6 AP connectivity, IP surveillance and mobility. Includes 1-year of Insight Premium or Pro subscription.

More from 10-Gigabit Switching

NETGEAR XS724EM-100EUS 24-Port 10G/Multi-Gigabit Plus Switch with 2 Dedicated SFP+ Ports

Enquire with us

Sold Out

NETGEAR 12-Slot Modular Stackable Managed Switch with 8-port 10G and 2-port 40G expansion cards

NETGEAR 12 Empty Slot Modular Stackable Managed Switch with 8-port 10G and 2-port 40G expansion cards

Sold Out

NETGEAR MS510TXM 8-Port Multi-Gigabit/10G Ethernet Smart Switch with 2 SFP+ Ports

NETGEAR 8-Port 10G Multi-Gigabit Ethernet Smart Switch (MS510TXM) - Managed, 8 x Multi-gig Ports, 2 x 10G SFP+, Optional Insight Cloud Management

Sold Out

NETGEAR MS510TXUP 8-Port Multi-Gigabit/10G Ethernet Ultra60 PoE++ Smart Switch with 2 SFP+ Ports

Sold Out

NETGEAR GS728TXP 28-Port Gigabit/10G Stackable Smart Managed Pro PoE Switch - with 24 x PoE+ @ 195W

Sold Out

NETGEAR 24-Port Fully Managed Switch M4300-28G-PoE+, 24x1G PoE+, 2x10GBASE-T, 2xSFP+, Stackable, 1000W PSU, ProSAFE Lifetime Protection (GSM4328PB)

NETGEAR GSM4328PB 24-Port Fully Managed Switch M4300-28G-PoE 1000W PSU

Enquire with us

Back to 10-Gigabit Switching

Specifications Data Sheet Installation Guide User Manual

Features

Traffic Management

Auto Negotiation of speed and duplex modes IEEE 802.3x Flow Control
Dynamic MAC address management
IEEE 802.1Q-based VLAN
Auto Voice VLAN
Auto Video VLAN (selected models)
VLAN routing (selected models)
QoS based on WRR, strict priority, or both
Port-based and IEEE 801.2p-based QoS
TCP/UDP-based QoS
DiffServ
IPv4 and IPv6-based QoS (selected models)
DSCP Support
Rate Limiting (ingress, or egress)
Link Aggregation and LACP

Switch Management

Insight mobile app or Insight Cloud Portal
Web browser-based management GUI
Smart Control Center Software for multi-switch management
IP Access List
IPv6 Management
Configurable Management VLAN
SNMP v1/v2c and v3
Standard MIBs (RFC1213, RFC1643, and RFC1493)
RMON group 1, 2, 3, 9
Firmware Upgrade through Smart Control Center (TFTP)
Firmware download (to switch) and upload (to server) through TFTP/HTTP
Configuration and Image Upload (to PC) through HTTP Configuration Download (to Switch) thru TFTP/HTTP and upload (to server)
Memory & FLASH log
Syslog (server)
System password protection

NETGEAR IP Camera and WiFi Automation

Simplify the onboarding process of IP cameras and wireless access points to provide better Quality of Service (QoS) and auto-enabling multicast with the Auto-Camera and Auto-WiFi feature
Provides classification for digital camera and wireless access point packets.
Automatically places in a camera and wireless access point VLAN and then be prioritized above other packets

Room to Move

5 different ports available: 1G, 2.5G, 5G, 10G; SFP+ and cCopper

295W PoE Conveniance

With 8 uninterrupted PoE ports, deploy PoE-based VoIP phones, IP cameras, AV-over-IP endpoints and wireless access points simply and securely.

Cloud Management

Optional remote access for configuration, management, and monitoring through the NETGEAR Insight Cloud Portals

Specifications

Product Number

MS510TXUP

Physical Specifications

Dimensions (W x D x H) : 330 x 206 x 43 mm (13.0 x 8.12x 1.7 in)

Weight : 2.51 kg (5.53 lb)

Multi-gigabit copper ports

4 (1G/2.5G)

Multi-gigabit/10 Gigabit copper ports

4 (1G/2.5G/5G/10G)

SFP+ ports

Number of PoE++ (802.3bt) ports

Total PoE Power budget

295 Watts

Uninterrupted PoE

Yes

Max MAC entries

32K

Buffer size

16Mbit

VLAN (Number Supported)

256

VLAN routing

Yes

Dynamic VLAN assignment

Yes

MLD Snooping

Yes

Static route

Yes (32)

Host ARP table

512 ARP

EEE

Yes

DoS Prevention

Yes

Internal/External PSU

Internal

Max power (worst case, all ports used, line-rate traffic)

380W

Fans

Acoustic Noise Level @25C

33.0 dBA

Operating Temperature

0° to 50° C (32 to 122F)

MTBF

848,553 hrs (96.9 yrs)

Warranty

Limited Lifetime Hardware Warranty .
